Specifications

• PRICING

  add remove
  • Price:
    Standard
  • MSRP:
    22799
  • MSRP + Destination:
    22799
  • Currency:
    US Dollars
  • Warranty (Months):
    24
  • Warranty (Condition):
    Limited
  • Battery Warranty (Months):
    60
• ENGINE

  add remove
  • Engine:
    Standard
  • Engine Brand Name:
    Revelation™
  • Engine Type:
    Electric
  • Horsepower (bhp):
    100
  • Horsepower (kW):
    75
  • Torque (Ft Lbs):
    84
  • Torque (Nm):
    113.9
  • Valve Configuration:
    Not Available
  • Turbocharged:
    No
  • Supercharged:
    No
  • Starter:
    Electric
  • Fuel Type:
    Electric
  • Maximum Range (mi):
    146
  • Maximum Range (km):
    235
  • Carburetion:
    Not Available
  • Fuel Injector:
    No
  • Carburetor:
    No
  • Parental Controls:
    Not Available
  • Other Engine:
    Not Available
• ELECTRIC ENGINE

  add remove
  • Electric Engine:
    Standard
  • Electric Motor Type:
    DC
  • Maximum Engine Range (Miles):
    146
  • Maximum Engine Range (km):
    235
  • Battery:
    Standard
  • Battery Type:
    Lithium Ion
  • Number of Batteries:
    1
  • Battery Capacity (Watts):
    15500
  • Battery Capacity (KWh):
    15.5
  • Maximum Battery Capacity (Watts):
    15400
  • Maximum Battery Capacity (kWh):
    15.4
  • Battery Charging System:
    Standard
  • Battery Current Type:
    DC
  • Battery Input Type:
    J1772
  • Charging Level:
    Level 1 / Level 2 / Level 3
  • Battery Charging System Location:
    Onboard
  • Variable Charging Time:
    Yes
  • Minimum Charging Time (Minutes):
    40
  • Full Charging Time Minutes (120V):
    60
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Automatic
  • Number Of Speeds:
    1
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Belt
  • Reverse:
    No
  • Heel Toe Shifter:
    Not Available
  • Adjustable Throttle:
    Not Available
  • Other Transmission:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (in):
    84.1
  • Length (mm):
    2136.1
  • Width (in):
    32.8
  • Width (mm):
    833.1
  • Height (in):
    42.4
  • Height (mm):
    1077
  • Wheelbase (in):
    58.7
  • Wheelbase (mm):
    1491
  • Ground Clearance (in):
    5.1
  • Ground Clearance (mm):
    129.5
  • Weight:
    Standard
  • Wet Weight (lbs):
    562
  • Wet Weight (kg):
    254.9
  • Capacities:
    Standard
  • Performance:
    Standard
• EXTERIOR

  add remove
  • Construction:
    Standard
  • Frame:
    Aluminum
  • Body Material:
    Aluminum
  • Floor Boards:
    Not Available
  • Foot Pegs:
    Standard
  • Foot Peg Location:
    Driver and Passenger
  • Hand Grips:
    Standard
  • Handlebars:
    Standard
  • Handlebar Pads:
    Not Available
  • Exterior Guards:
    Standard
  • Belt Guard:
    Yes
  • Brush Guard:
    No
  • Chain Guard:
    No
  • Chassis Protectors:
    Yes
  • Drive Shaft Guard:
    No
  • Engine Case Guard:
    Yes
  • Exhaust Guard:
    No
  • Fork Guards:
    No
  • Hand Guards:
    No
  • Heel Guards:
    No
  • Light Guard:
    No
  • Tank Guard:
    No
  • Exterior Covers:
    Standard
  • Fuel Tank Cover:
    No
  • Radiator Cover:
    No
  • Side Cover:
    No
  • Front Fender:
    Standard
  • Front Fender Trim:
    Not Available
  • Front Fender Rail:
    Not Available
  • Rear Fender:
    Standard
  • Rear Fender Trim:
    Not Available
  • Rear Fender Rail:
    Not Available
  • Top Crown:
    Standard
  • Tank Divider:
    Standard
  • Pocket:
    No
  • Stand:
    Standard
  • Stand Type:
    Kick
  • Upper Fairing:
    Not Available
  • Lower Fairing:
    Not Available
  • Spoiler:
    Not Available
  • Skid Plate:
    Not Available
  • Wind Deflector:
    Not Available
  • License Plate:
    Standard
  • Other Exterior:
    Not Available
• STEERING

  add remove
  • Steering:
    Standard
  • Steering Control:
    Handlebar
  • Other Steering:
    Not Available
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Brand Name:
    Showa® SFF-BP®
  • Front Suspension Type:
    Inverted Fork
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension:
    Standard
  • Rear Suspension Brand Name:
    Showa® BFRC
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
  • Other Suspension:
    Not Available
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tires:
    Standard
  • Tire Brand:
    Michelin®
  • Front Tire Width:
    120
  • Front Tire Aspect Ratio:
    70
  • Front Tire Speed Rating:
    W
  • Front Wheel Diameter:
    17
  • Rear Tire Width:
    180
  • Rear Tire Aspect Ratio:
    55
  • Rear Tire Speed Rating:
    W
  • Rear Wheel Diameter:
    17
  • Front Tire (Full Spec):
    H-D®/Michelin® Scorcher® Sport 120/70 ZR17 58W
  • Rear Tire (Full Spec):
    H-D®/Michelin® Scorcher® Sport 180/55 ZR17 73W
  • Spare Tire:
    Not Available
  • Other Wheels & Tires:
    Not Available
• BRAKES

  add remove
  • Brakes:
    Standard
  • Brake Brand Name:
    Brembo® Monobloc
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    11.8
  • Front Brake Diameter (mm):
    300
  • Rear Brake Type:
    Hydraulic Disc
  • Anti-Lock Brakes:
    Standard
  • Regenerative Braking:
    Standard
  • Other Brakes:
    Not Available
• SEATS

  add remove
  • Seat:
    Standard
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Specifications:
    Standard
  • Seat Height (in):
    30
  • Seat Height (mm):
    762
  • Number Of Seats:
    2
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Not Available
  • Seat Tail Cover:
    Optional
  • Seat Rail:
    Not Available
  • Grab Rail or Strap:
    Standard
  • Heated Seat:
    Not Available
  • Sidecar:
    Not Available
  • Other Seat:
    Not Available
• GLASS

  add remove
  • Folding:
    Yes
  • Rearview Mirrors:
    Standard
  • Windshield:
    Optional
  • Sidecar Windshield:
    Not Available
  • Windshield Wipers:
    Not Available
  • Other Glass:
    Not Available
• INSTRUMENTATION

  add remove
  • Digital Instrumentation:
    Standard
  • Clock:
    Standard
  • Speedometer:
    Standard
  • Trip Odometer:
    Standard
  • Trip Computer:
    Standard
  • Compass:
    Not Available
  • Navigation System:
    Not Available
  • Lap Timer:
    Not Available
  • Fuel Level Warning:
    Not Available
  • Oil Pressure Gauge:
    Not Available
  • Shift Light:
    Not Available
  • Service Reminder:
    Standard
  • Multi-Lingual Instrumentation:
    Not Available
  • Battery Status Gauge:
    Standard
  • Other Instrumentation:
    Not Available
• STORAGE

  add remove
  • Hard Side Cases:
    Not Available
  • Fork Bag:
    Not Available
  • Tail Bag:
    Not Available
  • Tank Bag:
    Not Available
  • Leather Storage:
    Not Available
  • Glove Box / Dash Storage:
    Not Available
  • Front Rack:
    Not Available
  • Front Rack Storage:
    Not Available
  • Rear Rack:
    Not Available
  • Rear Rack Storage:
    Not Available
  • Side Rack:
    Not Available
  • Side Rack Storage:
    Not Available
  • Bag Liners:
    Not Available
  • Cupholder:
    Not Available
  • Sidecar Storage Cover:
    Not Available
  • Map Holder:
    Not Available
  • Helmet Storage:
    Not Available
  • Sidecar Front Rack:
    Not Available
  • Sidecar Rear Rack:
    Not Available
  • Sidecar Fender Rack:
    Not Available
  • Sidecar Trunk:
    Not Available
  • Other Storage:
    Not Available
• LIGHTS

  add remove
  • Headlight(s):
    Standard
  • Type:
    LED
  • Halogen Headlight(s):
    Not Available
  • Adjustable Headlights:
    Not Available
  • Fog Lights:
    Not Available
  • Headlight Mounts:
    Standard
  • Headlight Mounting Bar:
    Not Available
  • Headlight Visor:
    Standard
  • Turn Signal Visor:
    Not Available
  • Passing Lamps:
    Not Available
  • Passing Lamp Visors:
    Not Available
  • Other Lights:
    Not Available
• CONVENIENCE

  add remove
  • Engine Immobilizer:
    Standard
  • Engine Immobilizer Brand:
    Digitally Encoded Security System™ (DESS)
  • Heated Hand Grips:
    Not Available
  • Keyless Ignition:
    Not Available
  • Power Outlet:
    Standard
  • Cruise Control:
    Standard
  • Adjustable Handlebars:
    Not Available
  • Adjustable Levers:
    Not Available
  • Alarm System:
    Not Available
  • Handlebar Lock:
    Standard
  • First Aid Kit:
    Not Available
  • Other Convenience:
    Not Available
• AUDIO & COMMUNICATION

  add remove
  • Speakers:
    Standard
  • Cassette Player:
    Not Available
  • CD Player:
    Not Available
  • CB Radio:
    Not Available
  • Intercom:
    Not Available
  • Headset:
    Not Available
  • Wireless / Connectivity:
    Standard
  • Bluetooth® Audio:
    Yes
  • Mobile App Instrumentation:
    Yes
  • Other Audio & Communication:
    Not Available
• MOUNTS

  add remove
  • Saddle Bag Mounts:
    Not Available
  • Side Case Mount:
    Not Available
  • Windshield Mounts:
    Optional
  • Other Mounts:
    Not Available
• PAINT & FINISH

  add remove
  • Paint:
    Standard
  • Secondary Color:
    Not Available
  • Decal Kit:
    Not Available
  • Other Paint & Finish:
    Not Available
• SPECIAL PACKAGE

  add remove
  • Special Package:
    Optional
