‹ Home › Collection › Harley-Davidson^® › 2025 H-D^® Motorcycles › Sport › Sportster^® S

2025

Sportster^® S

Click to Request Details

2025 Sportster^® S

Engineered to thrill, the Sportster^® S is built around the big and powerful Revolution^® Max 1250T engine that puts out 121 horsepower and 93 ft-lb of torque. With rider-assist electronics, optimized handling, and a lightweight frame, this next-generation Sportster is all about performing rather than conforming.

Billiard Gray
Vivid Black
Brilliant Red
Mystic Shift
360

Disclaimer: Vehicle shown may vary visually by market and may differ from vehicles manufactured and delivered. Availability may vary by market, please see your local dealer for details.

Key features

Revolution® Max 1250T Engine

Next-generation, liquid-cooled Revolution Max engine with variable valve timing provides 121 horsepower and 94 ft-lb of torque through a wide rev range.

Specifications

Pricing

add remove
- Base MSRP

  $15,999
- Vivid Black

  $500
- Premium Solids

  $750
- Custom Color

  $900
- California Emissions

  $200
- Freight

  $730
Dimensions

add remove
- Length

  89.4 in
- Overall width

  33.1 in
- Overall height

  42.7 in
- Seat height, unladen

  30.1 in
- Ground clearance

  3.5 in
- Rake (steering head)

  30
- Trail

  5.8 in
- Wheelbase

  59.8 in
- Tires, front specifications

  160/70TR17 73V
- Tires, rear specifications

  180/70R16 77V
- Fuel Capacity

  3.1 gal
- Oil capacity

  4.75 qt.
- Weight, as shipped

  487 lbs
- Weight, in running order

  502 lb
- Tire, type

  Dunlop® Harley-Davidson Series, radial
- Fork angle

  28
- Reserve fuel capacity, fuel injection

  0.8 gal
- Gross axle weight rating, front

  359 lbs
- Gross axle weight rating, rear

  595 lbs
Engine

add remove
- Engine

  Revolution® Max 1250T
- Bore

  4.1 in
- Stroke

  2.8 in
- Displacement

  76.40 in³
- Compression ratio

  12.0:1
- Fuel system

  Electronic Sequential Port Fuel Injection (ESPFI)
- Exhaust

  2-into-1-into-2; catalyst in muffler
Performance

add remove
- Engine torque testing method

  J1349
- Engine torque

  92.2 ft-lb
- Engine torque (RPM)

  6000
- Horsepower

  121 HP / 90 kW @ 7500 rpm
- Lean angle, right (deg.)

  35
- Lean angle, left (deg.)

  35
- Fuel economy testing method

  Estimated City/Hwy
- Fuel economy

  49 mpg (5.1 l/100km)
- Lean angle testing method

  J1168
Powertrain

add remove
- Primary drive

  Gear, 49/89 ratio
- Gear ratios (overall) 1st

  12.21
- Gear ratios (overall) 2nd

  9.022
- Gear ratios (overall) 3rd

  6.994
- Gear ratios (overall) 4th

  5.641
- Gear ratios (overall) 5th

  4.731
- Gear Ratios (overall) 6th

  4.131
Chassis

add remove
- Front fork

  43 mm inverted fork with compression, rebound and spring preload adjustability. Aluminum fork triple clamps
- Rear shocks

  Linkage-mounted, piggyback monoshock with compression, rebound and hydraulic spring preload adjustability
- Wheels, front type

  Aluminum cast, satin black
- Wheels, rear type

  Aluminum cast, satin black
- Brakes, type

  Front: single rotor, floating, tower- mounted Rear: solid uniform expansion rotor
- Brakes, caliper type

  Front: radially mounted, monoblock, 4-piston caliper Rear: floating, single piston caliper
- ABS

  Standard
Infotainment

add remove
- Screen size

  4 in
- Type

  Color TFT
- Headset specifications (if equipped)

  Bluetooth
- Languages

  Arabic, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (default), Finnish, French (Canada/France), German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal/Brazil), Indonesian, Russian, Slovak, Spanish (Mexico/Spain), Swedish, Thai, Turkish, Vietnamese
- Hands-free mobile phone — via Bluetooth

  Standard
- Voice Recognition Languages: Phone functions only

  Phone dependent
- Voice Recognition Languages: Tuner / Media / Navigation

  Phone dependent
- Text-to-Speech (TTS) languages

  Phone dependent
- Rider / passenger intercom

  Headset function only
- Vehicle information screen

  TPMS, Engine temp, Battery Voltage, Ambient Air Temp
- USB

  Charging and Instrument update, USB-C, 5V, 3A
- Bluetooth

  Phone/Media Supported
Color options

add remove
- Billiard Gray
- Vivid Black
- Brilliant Red
- Mystic Shift
